200T Pressure High Automatic Perforating Machine for Max 20mm Thickness Gypsum Board Punching

200T Pressure High Automatic Perforating Machine for Max 20mm Thickness Gypsum Board Punching

Nama merek:	LVJOE
Nomor Model:	LV-CK01
Moq:	1 Set
harga:	US $20000-80000
Kemampuan Penyediaan:	50 set per tahun

Informasi Rinci

Deskripsi Produk

Informasi Rinci

Tempat asal:

Cina

Sertifikasi:

ISO CE

Nama Produk:

Peralatan Perforasi Papan Insulasi Suara Mesin Pukulan Papan Plester Berkecepatan Tinggi

Kata kunci:

Perforator Papan Gipsum Produksi Berkelanjutan

Tekanan:

80t, 160t, 200t

Penggunaan:

Papan Gypsum, MDF, HPL, Perforasi Papan Semen Serat

lubang:

Bulat, persegi

Tingkat Otomatis:

Otomatis Tinggi

Ketebalan:

Max. 20mm

Jaminan:

1 Tahun

Aplikasi:

Plafon dan Partisi Interior

Fitur:

UMUM

Kemasan rincian:

Film PE dibungkus

Menyediakan kemampuan:

50 set per tahun

Deskripsi Produk

Sound Insulation Board Perforating Equipment High Speed Plaster Board Punch Machine

High-performance gypsum board drilling equipment designed for precision perforation in various building materials.

Product Specifications

Pressure	80T, 160T, 200T
Usage	Gypsum Board, MDF, HPL, Fiber cement board perforation
Holes	Round, Square
Automatic Level	High automatic
Thickness	Max. 20mm

Technical Specifications

Punching pressure: 200 ton
Stroke: 30 mm
Max mold height closed: 260mm
Number of strokes: 50 times/minute
Slide surface: 210*1100mm
Working table: 300*1670mm
Spacing of both pole: 1350mm (load the max board width 1220mm)
Power of main motor: 22kw
Power of servo motor: 2.6kw (brand: Zhejiang yifeng)
Feeding accuracy: ±1mm
Maximum feeding rate: 100mm
Maximum feeding thickness: 20mm
Gross weight of machine: 11000kg
Overall dimension: 2300*1500*2300(H*L*W)

Applications

This perforation machine is designed for creating holes in various materials including gypsum ceiling board, MgO board, MDF, HPL, Fiber cement board, and metal sheets. Custom hole shapes are available to meet specific requirements. Comprehensive operational training is provided.
