Fully Automatic High Capacity Variable Speed PU PIR Sandwich Panel Production Line for Prefab House Cold Room

Fully Automatic High Capacity Variable Speed PU PIR Sandwich Panel Production Line for Prefab House Cold Room

Nama merek:	Greenson
Moq:	1
harga:	$700000-$800000
Ketentuan Pembayaran:	L/C,T/T

Informasi Rinci

Deskripsi Produk

Informasi Rinci

Tempat asal:

HEBEI

Nama Produk:

Lini Produksi Mesin Panel Dinding Atap PU PIR Otomatis Untuk Ruang Dingin Rumah Prefab

Kata kunci:

Mesin Pembuat Panel Sandwich Dinding Atap Poliuretan Otomatis Penuh

Warna:

Kebutuhan Pelanggan

OEM:

Fitur:

Penuh-Otomatis

Kemasan rincian:

Film plastik

Pelabuhan pengiriman:

tianjin

Jaminan:

1 Tahun

Aplikasi:

Dinding, atap dan partisi

Nilai Otomatis:

Otomatis

Deskripsi Produk

Automatic PU PIR Roof Wall Panel Machine Production Line For Prefab House Cold Room

Product Overview

This advanced production line features a rational structure, complete functionality, and easy operation. Designed for manufacturing high-quality rock wool sandwich panels through a fully automated continuous process.

Fully Automatic: Effortlessly produces high-quality sandwich panels
High Capacity: Handles large-scale production with efficiency
Variable Speed: Adjusts to match production needs for optimal output
Multiple Material Options: Suitable for color steel sheets, galvanized sheets, and aluminum sheets
Guaranteed Quality: Equipped with video factory inspection and mechanical test reports

Production Process

Complete automated workflow including feeding, profiling, gluing, heating, trimming, grooving, and cutting. Features precision low-speed metering pump with computer-controlled frequency regulation, accurate dosing, and stepless speed adjustment capabilities.

Product Capabilities

This production line can produce various flat and corrugated sheet types with the following specifications:

Sandwich panels: thickness 40-300 mm, width 950-1200 mm
High-strength corrugated composite boards: thickness 40-300 mm, width 950-980 mm
Compatible with color steel plates, aluminum plates, stainless steel plates, and other sheet materials

Technical Specifications

Material Type	Color steel sheet; Galvanized sheet; Aluminum sheet
Material Thickness	0.3-0.8 mm
Material Width	≤1250 Mpa
Suitable Panel Length	2000-18000 mm
Suitable Panel Width	500-1200 mm
Suitable Panel Thickness	30-250 mm (excluding corrugation height)
Production Speed	3-15 m/min (Adjustable)
Valid Length of Double Belt Conveyor	12000-42000 mm
Work Pressure on Pouring Foam	150-200 Bar
Total Power	660 kW / 300 kW
Total Dimensions	130000 * 15000 * 6000 mm (Length * Width * Height)

Tag:

PUF PIR PU Rock Wool Sandwich Panel Machine Production Line with 3-15m/min Adjustable Speed 40-300mm Thickness and 950-1200mm Width
