PLC System Controlled PVC Laminated Gypsum Board Machine with 1300mm Laminating Width and 15m/min Speed

PLC System Controlled PVC Laminated Gypsum Board Machine with 1300mm Laminating Width and 15m/min Speed

Nama merek:	LVJOE
Nomor Model:	1300FM01
Moq:	1 SET
harga:	US $20000-200000
Ketentuan Pembayaran:	L/C,T/T
Kemampuan Penyediaan:	50 set per tahun

Informasi Rinci

Deskripsi Produk

Informasi Rinci

Tempat asal:

Hebei, Cina (Daratan)

Sertifikasi:

CE ISO 9001

Nama Produk:

Mesin Pemotong Papan Dan Mesin Pengemas Termoplastik Papan Ubin Langit-langit Papan Gypsum Laminasi

Kata kunci:

Mesin ubin eternit

Voltase:

380V

Jaminan:

1 tahun

Dimensi (P*L*T):

12600*1950*1600

Tipe yang Didorong:

Sistem PLC

Berat:

3-30t

Fitur:

Mudah Dioperasikan

Kemasan rincian:

Paket standar untuk ekspor atau sesuai permintaan untuk PVC dan film PET menghadapi mesin pembuatan

Menyediakan kemampuan:

50 set per tahun

Menyoroti:

PLC System Gypsum Ceiling Tile Production Line

1300mm Laminating Width PVC Laminated Gypsum Board Machine

15m/min Laminating Speed Board Cutting Machine

Deskripsi Produk

Board Cutting Machine & Thermoplastic Packing Machine for PVC Laminated Gypsum Board Ceiling Tiles

This fully automatic cutting machine is engineered for PVC laminated gypsum board ceiling tile production, efficiently processing surface decorative materials including films, papers, and laminates for various board types.

Technical Specifications

Attribute	Value
Voltage	380V
Warranty	1 Year
Dimension (LWH)	1260019501600 mm
Driven Type	PLC System
Weight	3-30t
Features	Easy To Operate

Machine Capabilities

Parameter	Specification
Effective Laminating Width	≤1300mm
Sheet Thickness	5-30mm
Laminating Speed	15m/min
Speed Adjustment	Frequency conversion synchronous speed regulating
Electrical Control	PLC system
Film Material	PVC film, aluminum foils, decorative material
Installed Power	4kw

Standard Gypsum Ceiling Tile Sizes

595*595*8.0mm
603*603*8.0mm
600*1200*8.0mm

Operation Process

The machine precisely cuts laminated gypsum boards to required sizes according to saw gauge standards. Boards are placed on delivery rolls, processed through the cutting system twice for enhanced accuracy, and delivered as finished products. The system can be optionally equipped with a pulsed sack-duster.

Our Manufacturing Advantages

Competitive Pricing

Direct factory production with 15+ years of specialization in PVC laminated gypsum ceiling tile machinery

Superior Quality

Rigorous quality control standards throughout manufacturing

Comprehensive Service

Specialized international trading company focused on export business

Complete After-sales Support

Engineers provide production line design, installation, commissioning, and operator training
