rincian produk

Rumah Produk

Low Cost Gas Furnace Rock Wool Production Line with PLC Control and Adjustable Felt Size for Mineral Wool Board Manufacturing

Low Cost Gas Furnace Rock Wool Production Line with PLC Control and Adjustable Felt Size for Mineral Wool Board Manufacturing

Nama merek:	Greens
Moq:	1
harga:	US $2000000-4000000
Ketentuan Pembayaran:	L/C,T/T

Informasi Rinci

Deskripsi Produk

Informasi Rinci

Tempat asal:

Hebei

Nama Produk:

Lini Produksi Tungku Gas Berbiaya Rendah Untuk Mesin Pembuat Bahan Konstruksi Wol Mineral Batu

Kata kunci:

jalur produksi wol batu

Voltase:

380V atau disesuaikan

Ketebalan panel:

20-250mm

Kepadatan Panel:

30-200 kg/m³

menyampaikan kecepatan:

40 ~ 120 meter/menit

Lebar sabuk ayun:

2800mm

Motor sabuk ayun:

4KW (motor frekuensi variabel)

Keluaran (produk jadi):

3-4 ton/jam

Lebar produk minimum:

600 mm

Menyoroti:

Low Cost Gas Furnace Rock Wool Production Line

PLC Control Mineral Wool Board Production Line

Adjustable Felt Size Stone Wool Production Line

Deskripsi Produk

Low Cost Gas Furnace Production Line For Stone Rock Mineral Wool Construction Material Making Machinery

The drum-type cotton collecting machine is a comprehensive system for rock wool panel production, featuring advanced automation and efficient material handling capabilities.

Product Specifications

Product Name	Drum Collection Machine Wool Collecting And Pendulum System Rock Wool Production Line
Keyword	Rock wool sound insulation material production line
Voltage	380v Or Customized
Electric Control	PLC control
Condition	New
Conveying speed	40~120 meters/min
Swing belt width	2800mm
Swing belt motor	4kw (variable frequency motor)

Technical Specifications

Product Name: Rock wool Panel Production Line
Automatic Grade: Automatic
Voltage: 380V
Panel Thickness: 30-200mm
Felt Size: 1000mm (adjustable)
Panel Density: 30-200 Kg/m3
Applicable Industries: Manufacturing Plant, Retail, Construction works
Finished products: Rock wool board
Usage: Building Material Production

System Operation

The sturdy steel structure frame houses a bearing transmission system. The drum features a mesh plate with an installed negative pressure air induction chamber beneath. The fan creates negative pressure in the induction chamber, effectively pulling cotton fibers onto the stencil while filtering and emptying through the settling chamber.
