rincian produk

Rumah Produk

Fully Automatic Lamination Machine for Fireproof Aluminium Foil Back Gypsum Ceiling Tiles with 1300mm Lamination Width

Fully Automatic Lamination Machine for Fireproof Aluminium Foil Back Gypsum Ceiling Tiles with 1300mm Lamination Width

Nama merek:	Gypsum Ceiling Tiles Machine
Nomor Model:	Garis produksi genteng plafon
Moq:	1 set
harga:	dapat dinegosiasikan
Ketentuan Pembayaran:	Fob
Kemampuan Penyediaan:	10 set/tahun

Informasi Rinci

Deskripsi Produk

Informasi Rinci

Tempat asal:

Tiongkok

Sertifikasi:

Nama Produk:

Aluminium Foil Kembali Produsen Lini Produksi Ubin Langit-Langit Gipsum Dilapisi Vinyl Tahan Api

Kata kunci:

PVC Laminated Gypsum Board Ceiling Tiles Making Machine PVC Film Gypsum Board Lamination Machine

Bahan mentah:

Film PVC, papan gypsum, film hewan peliharaan

Mode makan papan:

Otomatis (tipe push 、 tipe hisap) opsional

Ketebalan papan:

5-30 mm

Kecepatan lini produksi:

15m/mnt

Ukuran:

595*595 ， 603*603 ， 1200*600mm

tegangan:

380V, 50Hz disesuaikan

Kemasan rincian:

Bingkai kayu atau film PVC

Menyediakan kemampuan:

10 set/tahun

Menyoroti:

Fireproof Gypsum Ceiling Tiles Production Line

Aluminium Foil Back Fully Automatic Lamination Machine

1300mm Lamination Width PVC Gypsum Board Lamination Machine

Deskripsi Produk

Aluminium Foil Back Fireproof Vinyl Coated Gypsum Ceiling Tiles Production Line

Key Features

High-speed production at 15m/min
Versatile size options: 595×595mm, 603×603mm, 1200×600mm
Handles board thickness from 5-30mm
Automatic board feeding options: push type or suction type
Effective lamination width: less than 1300mm
Stacking concentrated transportation system
CE certified with customizable voltage options

Technical Specifications

Parameter	Specification
Raw Materials	PVC Film, Gypsum Board, PET Film
Production Speed	15m/min
Board Thickness Range	5-30 mm
Standard Sizes	595×595, 603×603, 1200×600mm
Voltage	380V, 50HZ (Customizable)
Glue Type	Water Glue for PVC Film

Product Overview

Our fully automated gypsum ceiling tile production line represents cutting-edge technology in board lamination systems. Designed for maximum efficiency and precision, this machine streamlines production processes while delivering consistent, high-quality results.

The system's advanced automation reduces labor requirements while increasing output, making it ideal for businesses looking to optimize their manufacturing operations. With flexible configuration options, it adapts to various production environments and requirements.

Applications

This production line serves multiple industries including construction, interior design, and manufacturing. Its versatility makes it suitable for:

Commercial ceiling tile production
Decorative panel manufacturing
PVC laminated gypsum board production
Custom architectural element fabrication

Ordering Information

Detail	Information
Minimum Order	1 set
Delivery Time	60 days
Payment Terms	FOB
Annual Capacity	10 sets
Packaging	Wooden frame or PVC film
